Elara

etcd-compatible config store for Kubernetes — UI, RBAC, schema validation.

Elara is a Kubernetes service that speaks the etcd v3 wire protocol, so your services keep reading config with their existing etcd client — no new SDK. On top of that store it adds the parts bare etcd leaves out: a full operator Web UI, JSON Schema validation per path pattern, groups-based RBAC, and a consumer view that shows which pod reads which key. One binary, one bbolt file, no cluster to run.

• Drop-in for etcd v3 clients — point etcdctl or any etcd SDK at port 2379.
• Guardrails before storage — invalid config is rejected by JSON Schema, not discovered at runtime.
• Operator-friendly — browse, edit, diff, and audit config from a UI, with Casbin RBAC scoped by namespace.

New here? Start with the Quickstart, then read the Architecture overview.

Quickstart

Elara ships a demo build that seeds sample namespaces, keys, JSON Schemas, and simulated Kubernetes pod consumers so the UI has something to explore immediately. Build it and run it:

docker build --build-arg DEMO_MODE=true -t elara:demo .
docker run --rm -p 8080:8080 -p 2379:2379 elara:demo

Open http://localhost:8080 — the UI loads pre-populated with three namespaces (production, staging, dev), ~10 keys, and simulated k8s consumers reading them. Try editing production/api/limits.json to a bad value to watch schema validation reject the write. The etcd-compatible API is live at localhost:2379 at the same time.

See the Quickstart guide for a guided 5-minute tour, or the todo-app tutorial for a worked example with three services reading config live.

Deploy to Kubernetes

helm repo add elara https://sergeyslonimsky.github.io/elara
helm install elara elara/elara

See the Helm chart docs for prerequisites, values.yaml reference, and production configuration (ingress, persistence, resource limits).

Why Elara

Three things Elara gives you that a bare etcd cluster does not:

1. etcd v3 drop-in. Elara serves the etcd v3 gRPC API (KV, Watch, Maintenance, Cluster) on port 2379. Existing clients connect unchanged — Put, Get, Watch, prefix ranges, and resumable watches from a stored revision all work as they do against real etcd.

export ETCDCTL_API=3 ETCDCTL_ENDPOINTS=localhost:2379
etcdctl put /prod/services/billing/config.yaml "$(cat config.yaml)"
etcdctl watch --prefix /prod/services/billing/

1. JSON Schema validation per path pattern. Attach a JSON Schema (draft-07) to a glob pattern such as /services/** or /**/*.yaml. Every write is validated before it is stored; on failure the API returns the exact failing path, message, and schema keyword, and the stored config is untouched. The most specific matching pattern wins.

2. k8s-aware client observability. The Clients view shows each connected etcd consumer with its Kubernetes namespace, pod, and node, plus which key it is watching and at which revision — so you can see exactly which workloads depend on a config before you change it.

When NOT to use Elara

Elara is deliberately scoped. Reach for something else if you need:

• Percentage rollouts / A/B testing → use Unleash or GrowthBook.
• Service discovery / service mesh → use Consul or linkerd.
• A 99.99% HA guarantee today → run a bare etcd cluster. Elara is single-instance for now (see Roadmap).
• Secrets with automatic rotation → use Vault.

Elara vs. bare etcd

Elara keeps etcd's wire protocol and revision semantics, then adds the operator plane on top:

Feature	bare etcd	Elara
etcd v3 wire	yes	yes (drop-in)
Web UI	—	full operator UI
Schema validation	—	JSON Schema per path pattern
RBAC	role-based	Casbin groups + namespace domains
GitOps bundle	—	YAML/JSON export/import round-trip
Per-key consumer view	—	k8s-aware (namespace / pod / node)
Config history	revision only	full version history + side-by-side diff

Single-instance, on purpose. One binary, one bbolt file, one backup command — no cluster to operate, no quorum to reason about. The trade-off is that Elara is not yet highly available: bbolt holds an exclusive file lock, so exactly one instance runs at a time. If you need HA today, use a bare etcd cluster; if you want a simple, auditable config plane you can back up with cp, this is the trade Elara makes.

Architecture

Three client surfaces — the React Web UI, typed ConnectRPC clients, and any etcd v3 client — converge on one layered core and one bbolt store. See the Architecture page for the full diagram, layer table, ports, and links to the two architecture decision records:

• ADR 0001 — Usecase-owned transactions with context-injected tx handles
• ADR 0002 — Groups-only RBAC

Roadmap

Elara is early and pre-1.0. The store, etcd-compatible API, Web UI, schema validation, RBAC, webhooks, and Helm chart are working today; the API and on-disk format may still change before 1.0. The headline gap is high availability: Elara runs as a single instance because bbolt holds an exclusive file lock. Raft-based HA and pluggable storage backends (PostgreSQL, S3) are the main direction after 1.0.

Contributing

Contributions are welcome — see CONTRIBUTING.md for the dev setup, test commands, and conventions. Security issues should be reported privately per SECURITY.md, not as public issues.

License

MIT.
